Jandy Aquapure 1400 3-Port Cell | R0452400
Maintain continuous, automated chlorine production and soft, crystal-clear pool water with the Jandy AquaPure 1400 3-Port Replacement Cell Kit. Designed as an authentic direct replacement electrolytic cell for Jandy AquaPure and PureLink electronic salt water sanitizing systems, this cell sanitizes residential in-ground swimming pools up to 40,000 gallons.
Operating via electrolysis, the cell converts low concentrations of dissolved pool salt into pure, free chlorine right in the return plumbing line. Its solid-state titanium electrode plates are coated with precious metals to optimize chlorine generation efficiency and extend operating lifespan. Engineered in a flexible 3-port configuration, the cell housing allows for either straight 180-degree inline plumbing or a 90-degree elbow configuration to fit tight equipment pads. The kit includes the replacement cell body with union threads, three sealing O-rings, and a new 16-foot DC cell power cable.
Features
High-Capacity Output: Produces up to 1.25 pounds of pure chlorine per 24 hours of continuous runtime, effectively sanitizing in-ground pools up to 40,000 gallons.
Versatile 3-Port Plumbing Design: Accommodates straight-through flow or 90-degree corner orientations, providing flexible installation geometry on cramped equipment pads.
Self-Cleaning Reverse Polarity Technology: Periodically alternates the electrical polarity of the internal titanium blades to help shed mineral scale buildup and reduce manual acid-washing frequency.
Complete Replacement Kit: Comes packaged with the 3-port electrolytic cell housing, three union sealing O-rings, and a factory 16-foot DC power cord with quick-connect terminals.
Direct OEM Compatibility: Integrates seamlessly with existing Jandy AquaPure control centers and AquaLink RS automation panels without requiring plumbing repiping or software modifications.
Specs
| Product Type | Electrolytic Salt Chlorinator Replacement Cell |
| Pool Gallon Capacity | Up to 40,000 Gallons |
| Chlorine Production | Up to 1.25 lbs / 24 Hours |
| Plumbing Configuration | 3-Port Body (Straight Inline or 90-Degree Return) |
| Pipe Size Compatibility | 2" to 2.5" PVC Unions |
| Cable Length | 16-Foot Heavy-Duty DC Power Cable Included |
| Electrode Material | Titanium Blades with Ruthenium Oxide Coating |
| Salinity Range | 3,000 to 3,500 ppm (Nominal 3,200 ppm) |
| System Compatibility | Jandy AquaPure 1400, PureLink, ClorMatic Systems |
| Manufacturer | Jandy / Fluidra |
| Part Number | R0452400 |
